SS Speed Control Unit (K Series)| Luyang Separate Controller for Flexible Installation

SS Separated Speed Controller

Product Description

SS11 / SS22 / SS11E / SS22E 【K Series】

SS separated speed controller is also called speed regulator. It is a product that controls the output speed of the motor by adjusting the voltage. It can adjust the output speed according to the equipment requirements.

Compactness.
Easy operation.
Attach external volume.

Q'ty :

Inquiry

Available for 6W~150W motors.
Available for single phase motors.
Control volume can be separated from body.

SPECIFICATION SHEET

Model	Type	Voltage	Frequency	Suitable For Output	Speed Range	Speed Rate Of Change	Velocity Reaction	Ambient Condition	Velocity Safety
SS11	Separated Speed Controller	AC100~110V Single Phase	60Hz	6W-150W	90~1600rpm	5%	0.5Sec	-10°C~50°C	◎
SS22	Separated Speed Controller	AC200~220V Single Phase	60Hz	6W-150W	90~1600rpm	5%	0.5Sec	-10°C~50°C	◎
SS11E	Separated Speed Controller	AC100V Single Phase	50Hz	6W-150W	90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
SS22E	Separated Speed Controller	AC200~240V Single Phase	50Hz	6W-150W	90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
