UX Digital Speed Controller

Product Description

UX206 / UX315 / UX425 / UX540 / UX560 / UX590 / UX5120 / UX5150 【K Series】

UX digital speed controller is a product for adjusting the speed of the motor. The controller is equipped with a digital display panel that can display the output speed of the motor and control the output speed by adjusting the voltage. It is suitable for speed control of single-phase motors.

Motor speed can be setted easily with the potentiometer on the front panel of the controller depends on customer's application.

Unit type, easy operation.
Easy connecting motor with connectors.

Q'ty :

Inquiry

Available for 6W~150W motors.
Available for single phase motors (built-in capacitor).
Control units combine the control pack and capacitor into one device.

SPECIFICATION SHEET

Model	Type	Voltage	Suitable For Output	Speed Range	Speed Rate Of Change	Velocity Reaction	Ambient Condition	Velocity Safety
UX206-□□	Digital Type Combination Speed Controller	AC power single phase	6W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX315-□□	Digital Type Combination Speed Controller	AC power single phase	15W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX425-□□	Digital Type Combination Speed Controller	AC power single phase	25W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX540-□□	Digital Type Combination Speed Controller	AC power single phase	40W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX560-□□	Digital Type Combination Speed Controller	AC power single phase	60W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX590-□□	Digital Type Combination Speed Controller	AC power single phase	90W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX5120-□□	Digital Type Combination Speed Controller	AC power single phase	120W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
UX5150-□□	Digital Type Combination Speed Controller	AC power single phase	150W	60Hz: 90~1600rpm 50Hz: 90~1350rpm	5%	0.5Sec	-10°C~50°C	◎
